For the previous generation, Core i9-9900K is the strongest game CPU in the industry, and it is one of the first choices for high-end players. However, as time went by, Intel released the tenth-generation processor. From the naming point of view, the CPU used to replace the i9-9900K is nothing more than the i9-10900K. However, the improvement of the tenth-generation processor this time is still considerable. In addition to the improvement in core performance, the multi-thread performance has been significantly improved, from 8 cores and 16 threads to 10 cores and 20 threads, and the overall performance has made a qualitative leap. We know that the interface types of the tenth-generation processors have all changed, so the previous generation 300 series motherboards are no longer supported, what motherboard does the i9 10900K match? Let’s share the popular knowledge about the best motherboard matching for Intel Core i9 10900K/F.
The difference between i9 10900K and i9 10900KF
The i9-10900K has a built-in UHD630 core display, while the i9-10900KF has no built-in core display, so the price is more affordable and cost-effective, but other parameters remain the same, so the performance is the same, and the matching motherboard is also the same.
So which motherboard is best for i9 10900K and i9 10900KF, then you need to know the interface type of this CPU first. After all, the interface type of the CPU must be consistent with the CPU slot of the motherboard to be compatible. A new generation of motherboards will also be listed. Regarding the Intel Core i9 10900K specifications, take a look at the following table.
Related Article: Best Motherboards for AMD Ryzen 9 5900X
Intel Tenth Generation Core i9 10900K Specification Sheet
| core architecture | Comet Lake |
| Interface Type | LGA1200 |
| core thread | 10 cores 20 threads |
| CPU frequency | 3.7GHz |
| Turbo Frequency | 5.3Ghz |
| memory support | DDR4-2933 |
| Core Graphics | UHD630 core display (i9-10900KF has no built-in core display) |
| L3 cache | 20MB |
| manufacturing process | 14nm |
| Design power consumption | 125W |
| Support overclocking | Support overclocking |
| Compatible Chipset | intel 400 series |
In terms of specifications, the Intel Core i9-10900K is based on the ancestral 14nm++ process technology, with 10 cores and 20 threads, the default main frequency is 3.7Ghz, the maximum turbo frequency is 5.3Ghz, the maximum core frequency is 4.8GHz, the third-level cache is 20MB, and the frequency is not locked. Support overclocking, built-in UHD630 core display, design power consumption 125W, and i9-10900KF have the same parameters except for no core display, so the performance is the same. In terms of interface, i9 10900K and i9 10900KF adopt the new LGA 1200 interface type, so they no longer support compatibility with 300 series motherboards, and need to be equipped with a new 400 series motherboard.
Related Article: BEST Motherboards For AMD Ryzen 9 5950X
What motherboard is good for i9-10900K?
Intel 10th generation processors are equipped with 400-series motherboards and listed simultaneously. In the Intel 400 series, there are Z490, H470, B460, and the entry-level H410 chipset. These motherboards are equipped with LGA 1200 slots, so they can Support and are best compatible with i9 10900K and i9 10900KF processors, but which one is the best match?
The i9 10900K and i9 10900KF processor models are suffixed with K, indicating that they support overclocking. Among them, H410 is positioned as an entry-level motherboard, which can basically be ruled out, while H470, a motherboard with an awkward middle position, is basically a product ignored by the market, and also does not support overclocking. , is also the highest specification among motherboards, so the high-end i9 10900K and i9 10900KF are best suited for Z490 motherboards and meet overclocking requirements.
The above is the intel Core i9 10900K/F best motherboard matching knowledge popularization shared. In fact, the basic specifications of the i9 10900K and i9 10900KF are the same, but the difference between the core display and the non-core display, so the performance is also the same, because The i9-10900KF does not have a built-in core graphics card, so it must be used with an independent graphics card to work normally, otherwise, the machine cannot be turned on. The best match for i9 10900K and i9 10900KF is the Z490 motherboard, which meets the overclocking requirements. Although the motherboard cannot determine the performance, it determines the stability and scalability of a computer, so the motherboard brands are recommended to choose the three major brands ASUS, Gigabyte, and MSI.
