Best Motherboards for AMD Ryzen 7 5700X

Best Motherboards for  Ryzen 7 5700X

On April 4, 2022, AMD 5000 series CPUs added new members and officially launched AMD Ryzen R7 5700X, R5 5600, and R5 5500, undoubtedly the mainstream CPU has a lot of new choices. R7 5700X is equipped with 8 cores and 16 threads, more suitable for design people or gamers, the performance is second only to R7 5800X, the performance is about 10% behind, but it is undoubtedly more affordable in price, the latter may be cheaper, after all, Intel 12 generation is currently taking the cost-effective route. So what motherboard is AMD Ryzen R7 5700X equipped with? The following installation home shares the motherboard recommendation of the Ryzen 7 5700X.

Before the motherboard is matched, let’s take a look at the parameters of the AMD Ryzen R7 5700X processor to understand the interface type, as shown in the following table.

AMD Ryzen™ 7 5700X parameters

CPU nameAMD Ryzen R7 5700X
Core architectureZen3
Interface typeAM4
Core threads8 cores and 16 threads
Process technology7 nm
Overclocking is supportedOverclocking is supported
Base frequency3.4Ghz
Acceleration frequency4.6GHz
L3 cache32MB
Built-in core displayNo built-in kernel display
Memory support3200MHz
TDP power consumption65W
PCIe4.0In the tank
Best motherboardB550

In terms of parameters, AMD Ryzen 7 5700X adopts the most advanced 7nm process at present, using the design still based on AM4 interface, with 8 cores and 16 threads, basic frequency 3.4GHz, acceleration frequency 4.6GHz, advanced cache, equipped with 32MB L3 cache and 4MB L2 cache, and the memory supports dual-channel DDR4-3200MHz, no built-in core graphics card, need to purchase a separate discrete graphics card, thermal design power consumption of 65W, positioning high-end products. From the parameter point of view, R7 5700X is more like R7 5800X skin version, only the frequency is slightly reduced, so the power consumption and CPU heat is smaller than R7 5800X, other parameters are basically the same, from the paper parameters can be seen R7 5700X and R7 5800X, the comprehensive performance difference is expected to be controlled within 10%.

Related Article: Best motherboards for Core i9-13900K

What is the best motherboard for AMD Ryzen R7 5700X?

As for what motherboard the CPU is suitable for, I believe this is already a cliché topic. AMD Ryzen™ 7 5700X still uses AM4 interface, each new processor is launched, and matching new motherboards will also be launched, R7 5700X is best suited for 500 series motherboards. At present, AMD 500 series motherboards have A520, B550, X570 motherboards, of which A520 motherboards are positioned as entry-level, only suitable for some entry-level CPUs, such as Ryzen R3 series or below models, and positioning high-specification X570 motherboards are not necessary, with the loss of cost performance, R7 5700X preferred positioning mid-range mainstream B550 motherboards, to meet power supply and overclocking needs. B550 motherboard recommended examples:

ASUS TUF GAMING B550M-PLUS HEAVY GUNNER MOTHERBOARD

The ASUS TUF Gaming B550M-PLUS Heavy Gunner motherboard is a microATX motherboard designed for use with AMD processors and AM4 sockets. It is part of the TUF Gaming line of motherboards, which are known for their durability and reliability.

Some key features of the B550M-PLUS Heavy Gunner motherboard include:

  • Support for AMD Ryzen processors, including 3rd and 4th generation processors
  • AM4 socket for AMD processors
  • MicroATX form factor
  • 4 DIMM slots for DDR4 RAM, with support for up to 128GB of memory
  • 2 PCIe 3.0 x16 slots and 1 PCIe 3.0 x1 slot for expansion cards
  • 6 SATA 3.0 ports for storage devices
  • 1 M.2 slot for NVMe SSDs
  • Gigabit Ethernet port for wired networking
  • 7.1-channel audio support
  • RGB lighting control
  • TUF Gaming’s Alliance with various hardware and software partners

Pros:

  • Designed for gaming and other high-performance applications, with support for fast memory and PCIe 4.0 connectivity
  • Solid military-grade build quality, with TUF components and an extended heatsink for improved durability and stability
  • Features an 8+2 phase power delivery system and active cooling for the VRM
  • Comes with a range of gaming-centric features, including Aura Sync RGB lighting, BIOS Flashback, and support for Sonic Studio III audio processing
  • Features an HDMI and DisplayPort video output, as well as Gigabit Ethernet and Wi-Fi 6 connectivity

Cons:

  • The micro ATX form factor may not be suitable for all users, depending on the size and design of their case
  • Some users may find the price to be on the higher side for a micro ATX motherboard
  • The motherboard only has two DIMM slots, which may limit the amount of RAM that can be installed
  • The BIOS may not be as user-friendly as some other models on the market

This motherboard is suitable for building a mid-range gaming PC or a general-purpose system. It offers a good balance of features and performance at a reasonable price.

MSI MAG B550M MORTAR mortar motherboard

The MSI MAG B550M Mortar motherboard is a microATX motherboard designed for use with AMD processors and AM4 sockets. It is part of the MAG (Mortar) series of motherboards, which are designed for gaming and offer a good balance of performance and features.

Some key features of the MAG B550M Mortar motherboard include:

  • Support for AMD Ryzen processors, including 3rd and 4th generation processors
  • AM4 socket for AMD processors
  • MicroATX form factor
  • 4 DIMM slots for DDR4 RAM, with support for up to 128GB of memory
  • 2 PCIe 3.0 x16 slots and 1 PCIe 3.0 x1 slot for expansion cards
  • 6 SATA 3.0 ports for storage devices
  • 1 M.2 slot for NVMe SSDs
  • Gigabit Ethernet port for wired networking
  • 6-channel audio support
  • RGB lighting control
  • MSI Mystic Light software for customizable lighting effects

Pros:

  • Designed for gaming and other high-performance applications, with support for fast memory and PCIe 4.0 connectivity
  • Features an extended heatsink and active cooling for the VRM, as well as a 10+2 phase power delivery system
  • Comes with a range of gaming-centric features, including RGB lighting, BIOS Flashback, and support for Audio Boost audio processing
  • Features an HDMI and DisplayPort video output, as well as Gigabit Ethernet and Wi-Fi 6 connectivity
  • Comes with a comprehensive software suite, including the MSI Dragon Center and MSI APP Manager

Cons:

  • The micro ATX form factor may not be suitable for all users, depending on the size and design of their case
  • Some users may find the price to be on the higher side for a micro ATX motherboard
  • The motherboard only has two DIMM slots, which may limit the amount of RAM that can be installed
  • The BIOS may not be as user-friendly as some other models on the market

This motherboard is suitable for building a mid-range gaming PC or a general-purpose system. It offers a good range of features and solid performance at a reasonable price.

MSI MAG B550M MORTAR WIFI MORTAR MOTHERBOARD (WITH WIRELESS NETWORK CARD)

The MSI MAG B550M Mortar WiFi motherboard is a microATX motherboard designed for use with AMD processors and AM4 sockets. It is equipped with a wireless network card, which allows you to connect to a wireless network without the need for a separate wireless adapter.

Some key features of the MAG B550M Mortar WiFi motherboard include:

  • Support for AMD Ryzen processors, including 3rd and 4th generation processors
  • AM4 socket for AMD processors
  • MicroATX form factor
  • 4 DIMM slots for DDR4 RAM, with support for up to 128GB of memory
  • 2 PCIe 3.0 x16 slots and 1 PCIe 3.0 x1 slot for expansion cards
  • 6 SATA 3.0 ports for storage devices
  • 1 M.2 slot for NVMe SSDs
  • Onboard WiFi 5 (802.11ac) for wireless networking
  • Gigabit Ethernet port for wired networking
  • 6-channel audio support
  • RGB lighting control
  • MSI Mystic Light software for customizable lighting effects

Pros:

  • Includes a wireless network card for WiFi connectivity, which can be convenient for users who do not want to use an Ethernet cable
  • Designed for gaming and other high-performance applications, with support for fast memory and PCIe 4.0 connectivity
  • Features an extended heatsink and active cooling for the VRM, as well as a 10+2 phase power delivery system
  • Comes with a range of gaming-centric features, including RGB lighting, BIOS Flashback, and support for Audio Boost audio processing
  • Features an HDMI and DisplayPort video output, as well as Gigabit Ethernet connectivity
  • Comes with a comprehensive software suite, including the MSI Dragon Center and MSI APP Manager

Cons:

  • The micro ATX form factor may not be suitable for all users, depending on the size and design of their case
  • Some users may find the price to be on the higher side for a micro ATX motherboard with WiFi connectivity
  • The motherboard only has two DIMM slots, which may limit the amount of RAM that can be installed
  • The BIOS may not be as user-friendly as some other models on the market

This motherboard is suitable for building a mid-range gaming PC or a general-purpose system that requires wireless connectivity. It offers a good range of features and solid performance, with the added convenience of onboard WiFi.

ASUS TUF GAMING B550M-PLUS WIFI HEAVY GUNNER MOTHERBOARD (WITH WIRELESS NETWORK CARD)

The ASUS TUF Gaming B550M-PLUS WiFi Heavy Gunner motherboard is a microATX motherboard designed for use with AMD processors and AM4 sockets. It is equipped with a wireless network card, which allows you to connect to a wireless network without the need for a separate wireless adapter.

Some key features of the B550M-PLUS WiFi Heavy Gunner motherboard include:

  • Support for AMD Ryzen processors, including 3rd and 4th generation processors
  • AM4 socket for AMD processors
  • MicroATX form factor
  • 4 DIMM slots for DDR4 RAM, with support for up to 128GB of memory
  • 2 PCIe 3.0 x16 slots and 1 PCIe 3.0 x1 slot for expansion cards
  • 6 SATA 3.0 ports for storage devices
  • 1 M.2 slot for NVMe SSDs
  • Onboard WiFi 6 (802.11ax) for wireless networking
  • Gigabit Ethernet port for wired networking
  • 7.1-channel audio support
  • RGB lighting control
  • TUF Gaming’s alliance with various hardware and software partners

Pros:

  • Includes a wireless network card for WiFi connectivity, which can be convenient for users who do not want to use an Ethernet cable
  • Designed for gaming and other high-performance applications, with support for fast memory and PCIe 4.0 connectivity
  • Solid military-grade build quality, with TUF components and an extended heatsink for improved durability and stability
  • Features an 8+2 phase power delivery system and active cooling for the VRM
  • Comes with a range of gaming-centric features, including Aura Sync RGB lighting, BIOS Flashback, and support for Sonic Studio III audio processing
  • Features an HDMI and DisplayPort video output, as well as Gigabit Ethernet connectivity

Cons:

  • The micro ATX form factor may not be suitable for all users, depending on the size and design of their case
  • Some users may find the price to be on the higher side for a micro ATX motherboard with WiFi connectivity
  • The motherboard only has two DIMM slots, which may limit the amount of RAM that can be installed
  • The BIOS may not be as user-friendly as some other models on the market

This motherboard is suitable for building a mid-range gaming PC or a general-purpose system that requires wireless connectivity. It offers a good balance of features and performance, with the added convenience of onboard WiFi. The WiFi 6 capability of this motherboard offers faster speeds and better overall performance compared to previous WiFi standards.

Related Article: Best Motherboard for i7 13700K

GIGABYTE Xiaodiao B550M AORUS ELITE MOTHERBOARD

Gigabyte Xiaodiao B550M Aorus Elite is a micro ATX motherboard based on the AMD B550 chipset. It is designed for use with AMD Ryzen processors in the AM4 socket.

Some key features of the Gigabyte Xiaodiao B550M Aorus Elite motherboard include:

  • Support for AMD Ryzen processors in the AM4 socket
  • 4x DDR4 DIMM slots with support for up to 128GB of RAM
  • 1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x16 slot (x4 electrical), 1x PCIe 3.0 x1 slot
  • 6x SATA 6Gbps ports, 2x M.2 slots (1x PCIe 4.0 x4, 1x PCIe 3.0 x4)
  • Realtek ALC1200 audio codec with Nichicon audio capacitors and ESS Sabre Hi-Fi 9218 DAC
  • Gigabit Ethernet LAN with Realtek 2.5G LAN chip
  • HDMI, D-Sub, and DVI-D display outputs
  • 8+3 phase direct power delivery design
  • RGB Fusion 2.0 lighting support

Pros:

  • Support for AMD Ryzen processors in the AM4 socket
  • 4x DDR4 DIMM slots with support for up to 128GB of RAM
  • 1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x16 slot (x4 electrical), 1x PCIe 3.0 x1 slot
  • 6x SATA 6Gbps ports, 2x M.2 slots (1x PCIe 4.0 x4, 1x PCIe 3.0 x4)
  • Realtek ALC1200 audio codec with Nichicon audio capacitors and ESS Sabre Hi-Fi 9218 DAC
  • Gigabit Ethernet LAN with Realtek 2.5G LAN chip
  • HDMI, D-Sub, and DVI-D display outputs
  • 8+3 phase direct power delivery design
  • RGB Fusion 2.0 lighting support

Cons:

  • The micro ATX form factor may not be suitable for all users, depending on the size and design of their case
  • Some users may find the price to be on the higher side for a micro ATX motherboard
  • The BIOS may not be as user-friendly as some other models on the market

The Gigabyte Xiaodiao B550M Aorus Elite motherboard also includes a range of features designed to improve system stability and performance, such as an extended VRM heatsink, Smart Fan 5 technology, and Q-Flash Plus BIOS update utility. It is an ideal motherboard for building a high-performance micro ATX system based on AMD Ryzen processors.

The above is to share AMD Ryzen R7 5700X and motherboard matching knowledge, this processor is best matched with the mainstream B550 motherboard, and the R7 5800X performance difference is not much, but power consumption and heat generation will be better, perhaps the emergence of R7 5700X is a disguised price reduction, motherboard brand recommended to prefer the first-line brand Asus, Gigabyte, MSI, etc., the second line can choose ASRock, I hope this article can help everyone, pay attention to the installation home, get more computer hardware knowledge.
